SOUNDWALL
SOUNDWALL is a high-performance acoustic panel system featuring decorative wooden slats designed for installation on walls and ceilings. The system combines effective sound absorption with refined architectural aesthetics, making it suitable for a wide range of residential, commercial, and specialized interior spaces.
Each panel is manufactured as a composite acoustic element, consisting of a 12 mm polyester fiber (PET) acoustic backing combined with 8 mm wooden slats available in MDF, Iroko, or Oak. The panels are supplied as factory pre-assembled units, ensuring consistent quality and easy installation.
Produced in a rectangular modular format, the panels are installed side-by-side to create a continuous, seamless surface on walls or ceilings. SOUNDWALL offers an elegant and visually striking acoustic solution, improving interior acoustics while remaining cost-effective and practical for modern architectural projects.
VIEW
AVAILABLE SIZES
Dimensions: 240 × 60 cm
Total Thickness: 2cm
Slat Width: 3 cm
Spacing (slat-to-slat): 1 cm
TECHNICAL DATA
TECHNICAL SPECIFICATIONS
INSTALLATION
Installation can be carried out by mechanical fixing or adhesive bonding to walls or ceilings.
SUSTAINABILITY
Panels are manufactured from sustainable materials, with PET felt made from recycled plastic and wood sourced from sustainably managed forests.
NON TOXIC
Wooden slats meet E0 formaldehyde emission standards (desiccator method), ensuring a low-emission and healthier indoor environment.
MOISTURE RESISTANCE
The wooden slats offer high moisture resistance due to the melamine resin content, allowing installation in areas such as kitchens and bathrooms when properly finished.
FLAME RETARDANT
Polyester Fiber: Class B-s1, d0 (EN 13501-1) – Wood: Class B-s2, d0 (EN 13501-1)
MAINTENANCE
Installation can be carried out by mechanical fixing or adhesive bonding to walls or ceilings.
ACOUSTIC SPECIFICATIONS
SOUND ABSORPTION
SoundWall: Sound class C (αw=0.52)
[according to ISO 354:2003 & ISO 11654:1997]
(standard total thickness of 20mm)
SoundWall Plus: Sound class B (αw=0.82)
[according to ISO 354:2003 & ISO 11654:1997]
(with additional backing material of mineral wool 50mm, total thickness 70mm)
MATERIALS AND COLORS
MATERIALS
Surface Slats: MDF, Iroko, or Oak (8 mm)
Acoustic Backing:PET acoustic panel (12 mm)
SOUNDWALL Plus Additional acoustic backing: 50 mm mineral wool layer for enhanced sound absorption.
Customization
Panels can be customized in size, finish, and configuration to meet the specific requirements of each project or application.
COLORS
FRONT
OPTION 1: MDF coloured
BLACK
GREY
LIGHT GREY
BROWN
BLUE
GREEN
YELLOW
OPTION 2:
Colour MDF wood (Ash or Iroko or White Oak)
ASH
IROKO
WHITE OAK
BACK
The 12 mm PET acoustic panel (100% polyester fiber board) is available in a wide range of colours from the PET colour chart, subject to availability, allowing flexible design options based on project requirements.
Notes:
Natural colour variations may occur, particularly in wooden slats, due to the natural characteristics of wood and the use of organic dyes.
Final surface tone may vary depending on the applied finish (varnish, oil, or wax).
DOWNLOADS AND SAMPLES
BROCHURE
Soundwall Brochure PDFPRODUCT AVAILABILITY AND SAMPLES
UNC always have stock of the product and samples of each one of it. Feel free to contact us, in order to setting up a meeting in our showroom.
